Solutions
Marine Filtration Solutions
As the core carriers for transoceanic transportation, fishing operations, and offshore engineering, ships operate under extreme conditions of high salt spray, humidity, and fluctuating fuel quality. Marine filters, serving as the "first line of defense" for engines, fuel systems, and hydraulic systems, directly impact navigation safety, equipment lifespan, and operating costs. Addressing the diverse applications and harsh conditions of marine environments is critical.
The salt content in marine air is 10–20 times higher than on land, accelerating corrosion of metal filter components. At the same time, high humidity causes air filter paper to absorb moisture and harden, sharply reducing filtration efficiency. If not handled promptly, this may lead to engine “surge,” resulting in a 5–10% drop in power output.
Marine fuels often have high sulfur content and contain numerous impurities. Fuel quality also varies significantly from port to port, which can lead to gum and asphaltene deposits. Traditional fuel filters struggle to cope, frequently clogging and causing injector wear. A single repair can cost hundreds of thousands of RMB, and in severe cases, may cause main engine shutdown (downtime losses can exceed RMB 100,000 per hour).
Filter media is made of glass fiber with a PTFE coating, which blocks more than 90% of salt spray corrosion. The PTFE coating also provides hydrophobic properties, preventing filter paper from absorbing moisture and clogging. Filtration efficiency remains above 99.9% for 0.3 μm particles.
The housing is made of 316L stainless steel (tested to withstand 1000 hours of salt spray), replacing traditional carbon steel to completely eliminate rust issues. A cyclone separator is added at the air inlet to pre-separate 60% of larger salt particles and water mist, reducing the load on the main filter element.
Application Database: Covers parameters for bulk carriers, container ships, tankers, fishing vessels, and yachts.
Example: A 100,000-ton bulk carrier main engine (Mitsubishi UE 8L80E) is fitted with air filter model ME-1200 and fuel filter model FC-8000.
An ocean-going fishing vessel (400 HP engine) uses seawater filter model SW-300 and lube oil filter model LO-500.
Customized Services: For specialized vessels such as icebreakers and offshore supply vessels, filters can be customized to withstand extreme conditions such as -40°C temperatures and 500 bar ultra-high pressure.
Spare Parts Strategy: Based on voyage duration (e.g., a trans-Pacific route of about 30 days), it is recommended to prepare 2–3 sets of consumable filter elements (such as fuel fine filters and air filters). Spare parts should be clearly labeled with model numbers, replacement tools, and procedures to enable crew to perform quick replacements in emergencies.
Air Filters: Inspect every 1000 hours, replace every 2000 hours (short-haul coastal vessels may reduce to 1500 hours).
Fuel Filters: Replace every 1500–2000 hours for heavy fuel oil main engines; every 800 hours for diesel auxiliary engines.
Seawater Filters: Inspect backwash function monthly; replace filter screens every 6 months.
Shut off relevant system valves and drain residual media (fuel, lube oil).
Ensure proper fit of sealing gaskets when installing new elements to avoid leakage.
After replacement, run the system under no-load for 5 minutes to purge air.
XuhaiFa marine filters are the “invisible lifeline” of ocean navigation. By using optimized materials for marine environments, enhancing filtration precision, and providing a comprehensive adaptation and maintenance system, they significantly reduce equipment failure risks. According to shipping data, high-quality filters can reduce main engine failures caused by contamination by up to 60%.
With these advantages, XuhaiFa ensures safe and efficient voyages, offering strong protection for ships sailing further into global trade and marine exploration.
Xuhaifa Filter Co., Ltd. is a modern enterprise that integrates research and development, production, sales, and services.
The JX0708 oil filter is an important automotive accessory designed specifically for JAC Yuejin models. With its excellent performance and reliable quality, it provides critical oil filtration protection for vehicle engines, ensuring stable operation and long life of the engine.
The JX0818 oil filter is a high-performance automotive accessory specially designed for Chaochai Yuchai models. With its excellent quality and reliable performance, it provides critical oil filtration protection for vehicle engines, ensuring stable operation and long life of the engine.
JX1008A capped oil filter is a high-performance auto part designed for Chaochai, Dongfeng, JAC light trucks and other models. With excellent quality and reliable performance, it provides critical oil filtration protection for vehicle engines, ensuring stable operation and long life of the engine.
JX1008A oil filter is a high-performance auto part designed for Chaochai, Dongfeng, JAC light trucks and other models. With excellent quality and reliable performance, it provides critical oil filtration protection for vehicle engines, ensuring stable operation and long life of the engine
The oil filter model JX1011 is specially designed for loaders, harvesters and other machines equipped with Yunnei engines, ensuring a perfect fit with the equipment and achieving efficient oil filtration.
K6000-1012240 oil filter is a high-performance accessory specially designed for C&C trucks and C&C heavy trucks. With its excellent quality and reliable performance, it provides critical oil filtration protection for vehicle engines, ensuring stable operation and long life of the vehicle.
The LF670 oil filter is an important accessory specially designed for Cummins generator sets. With its excellent quality and reliable performance, it provides critical oil filtration protection for the engine of the generator set, ensuring the stable operation and long life of the generator set.
The LF9080 oil filter is a high-performance accessory designed specifically for Cummins Tianlong flagship models. With its excellent quality and reliable performance, it provides critical oil filtration protection for the vehicle engine, ensuring the stable operation and long life of the vehicle.
LF16016 oil filter is a key auto part specially designed for Foton Aumark, Auman and vehicles equipped with Cummins engines. With excellent quality and reliable performance, it provides efficient oil filtration protection for vehicle engines, ensuring stable operation and long life of the engine.
LF17500 oil filter is a high-performance accessory designed specifically for Cummins Auman models. With its excellent quality and reliable performance, it provides critical oil filtration protection for vehicle engines, ensuring stable operation and long life of the vehicle.
